Development of a Global Mechanism for Ammonia Combustion Assisted by Machine Learning

Jieun Kang; Seong-kyun Im

doi:10.15231/jksc.2024.29.2.037

All Issue

2024 Vol.29, Issue 2 Preview Page Next Page

Research Article

Development of a Global Mechanism for Ammonia Combustion Assisted by Machine Learning 기계학습을 활용한 암모니아 연소의 총괄 반응식 개발

30 June 2024. pp. 37-43

PDF XML

Abstract

To achieve carbon neutrality, sustainable energy solutions like ammonia are being explored. Ammonia, with its high energy density and existing infrastructure, is promising as a hydrogen carrier. This study aims to reduce the computational cost of ammonia combustion simulations by developing a global mechanism using a chemical reaction neural network (CRNN). The CRNN was trained using data from the detailed mechanism by Okafor, resulting in a global mechanism with 4 reactions and 7 species. Performance evaluations showed that the developed global mechanism accurately predicts temperature, species concentrations and ignition delay times, achieving high prediction accuracy for steady-state conditions. The results indicate that the CRNN-based global mechanism significantly enhances computational efficiency and accessibility for ammonia combustion research.

Keywords

Ammonia combustion

Global reaction mechanism

Machine learning

Chemical reaction neural network

References

S. Sorrell, Reducing energy demand: A review of issues, challenges and approaches, Renewable and Sustainable Energy Reviews, 47 (2015) 74-82.

10.1016/j.rser.2015.03.002

H. Kobayashi, A. Hayakawa, K.K.A. Somarathne, & E.C. Okafor, Science and technology of ammonia combustion, Proceedings of the Combustion Inst., 37(1) (2019) 109-133.

10.1016/j.proci.2018.09.029

A.M. Elbaz, S. Wang, T.F. Guiberti, & W. L. Roberts, Review on the recent advances on ammonia combustion from the fundamentals to the applications, Fuel Commun., 10 (2022) 100053.

10.1016/j.jfueco.2022.100053

W.S. Chai, Y. Bao, P. Jin, G. Tang, & L. Zhou, A review on ammonia, ammonia-hydrogen and ammonia-methane fuels, Renewable and Sustainable Energy Reviews, 147 (2021) 111254.

10.1016/j.rser.2021.111254

E.C. Okafor, Y. Naito, S. Colson, A. Ichikawa, T. Kudo, A. Hayakawa, & H. Kobayashi, Experimental and numerical study of the laminar burning velocity of CH4-NH3-air premixed flames, Combustion and Flame, 187 (2018) 185-198.

10.1016/j.combustflame.2017.09.002

A.A. Konnov, Implementation of the NCN pathway of prompt-NO formation in the detailed reaction mechanism, Combustion and Flame, 156(11) (2009) 2093-2105.

10.1016/j.combustflame.2009.03.016

J. Otomo, M. Koshi, T. Mitsumori, H. Iwasaki, & K. Yamada, Chemical kinetic modeling of ammonia oxidation with improved reaction mechanism for ammonia/air and ammonia/hydrogen/air combustion, International Journal of Hydrogen Energy, 43(5) (2018) 3004-3014.

10.1016/j.ijhydene.2017.12.066

E.C. Okafor, Y. Naito, S. Colson, A. Ichikawa, T. Kudo, A. Hayakawa, & H. Kobayashi, Measurement and modelling of the laminar burning velocity of methane-ammonia-air flames at high pressures using a reduced reaction mechanism, Combustion and Flame, 204 (2019) 162-175.

10.1016/j.combustflame.2019.03.008

J.A. Miller, M.D. Smooke, R.M. Green, & R.J. Kee, Kinetic modeling of the oxidation of ammonia in flames, Combustion Science and Tech., 34(1-6) (1983) 149-176.

10.1080/00102208308923691

H. T. Nguyen, P. Domingo, L. Vervisch,, & P. D. Nguyen, Machine learning for integrating combustion chemistry in numerical simulations, Energy and AI, 5 (2021) 100082.

10.1016/j.egyai.2021.100082

G. Mao, T. Shi, C. Mao, & P. Wang, Prediction of NOx emission from two-stage combustion of NH3-H2 mixtures under various conditions using artificial neural networks, International Journal of Hydrogen Energy, 49 (2024) 1414-1424.

10.1016/j.ijhydene.2023.10.129

K. Wan, C. Barnaud, L. Vervisch, & P. Domingo, Chemistry reduction using machine learning trained from non-premixed micro-mixing modeling: Application to DNS of a syngas turbulent oxy-flame with side-wall effects, Combustion and Flame, 220 (2020) 119-129.

10.1016/j.combustflame.2020.06.008

L. Liu, F. Tan, Z. Wu, & Y. Wang, Combining genetic algorithm and deep learning to optimize a chemical kinetic mechanism of ammonia under high pressure, Fuel, 360 (2024) 130508.

10.1016/j.fuel.2023.130508

W. Ji & S. Deng, Autonomous discovery of unknown reaction pathways from data by chemical reaction neural network. The Journal of Physical Chemistry A. 125(4) (2021) 1082-1092.

10.1021/acs.jpca.0c0931633471526

W. Ji, X. Su, B. Pang, Y. Li, Z. Ren, & S. Deng, SGD-based optimization in modeling combustion kinetics: Case studies in tuning mechanistic and hybrid kinetic models, Fuel, 324 (2022) 124560.

10.1016/j.fuel.2022.124560

X. Su, W. Ji, J. An, Z. Ren, S. Deng, & C. K. Law, Kinetics parameter optimization of hydrocarbon fuels via neural ordinary differential equations, Combustion and Flame, 251 (2023) 112732.

10.1016/j.combustflame.2023.112732

P. Glarborg, The NH3/NO2/O2 system: Constraining key steps in ammonia ignition and N2O formation, Combustion and Flame, 257 (2023) 112311.

10.1016/j.combustflame.2022.112311

Information

Publisher :The Korean Society of Combustion
Publisher(Ko) :한국연소학회
Journal Title :Journal of the Korean Society of Combustion
Journal Title(Ko) :한국연소학회지
Volume : 29
No :2
Pages :37-43
Received Date : 2024-05-31
Revised Date : 2024-06-17
Accepted Date : 2024-06-17
DOI :https://doi.org/10.15231/jksc.2024.29.2.037
